NEB-U-TYKE IC – PENGUIN PEDIATRIC NEBULIZER 1 Respiratory

 • Small footprint and light weight provide exceptional portability • Compressor weighs only 3.5 lbs • Reliable, Piston-driven Compressor • Colorful, Child-Friendly • 5 year limited warranty • Designed to meet the requirements of HCPCS Code: E0570 The John Bunn Neb-u-Tyke Penguin Nebulizer comes complete with: 1 reusable nebulizer1 mouthpiece1 pediatric mask1 “T” adapter 1 PVC tubing3 spare filters Technical Specifications

Weight: (Compressor only)

3.5 lbs. (1.59 kg)

Dimensions: (Compressor only)

6.7"; x 4.8"; x 6.5";

Electrical Requirements:

115VAC 60Hz

Power Wattage:

68 watts under normal load

Ambient operation



Temperature Range:

41ºF to 104ºF (5ºC to 40ºC)

Transport/Storage



Ambient Temperature:

-13ºFto 158ºF (-25ºC to 70ºC)

Humidity:

10% to 90%

Method of nebulization

Oiless piston compressor

Operating voltage

115V – 60Hz

Class

Class II

Current

1.2A

Compressor flow range in liters/min

0-10 liters / min

Compressor pressure range in psi

0 – 32.5 psi

Nebulization Rate in ml/min

7 liters / min

Particle size range in microns

0.5 – 5 microns

Disposable nebulizer capacity in ml
